UNIVERSAL FLANGE WITH SPIGOT - (854.510.075 S)
Part Of the Series: Adaptor-flange-universal
Type no.: 854.510.075 S
EAN no.: 5705499138900
NRF no.: 2172734
UNIVERSAL FLANGE WITH SPIGOT
-Diameter: Ø75mm
-Equivalent to ANSI 3" / JIS65-80 5K-10K / DIN DN65-80 PN6-16
-Stainless steel: AISI316L/EN1.4404
Product Specification | |
---|---|
Material | AISI 316L |
Material (EN) | EN 1.4404 |
Minimum Height (mm) | 150 |
Number of Bolts | 4 |
Outlet Diameter (mm) | 75 |
Weight (kg) | 1,61 |
-
Downloads
-
Approval Information
For approval information, please refer to the below approval certificates.
HACCP Food Safety Programme - Australasia HACCP Food Safety Programme - Europe PL - Hygienic Certificate - All Products Achilles Certificate - 46702-22 Bureau Veritas, 02375-I0 Pipes & Fittings DNV - TAP0000023-rev4, Sanitary discharge pipes Lloyds Register LR22419510TA KR - Type Approval CPH42135-PE001 RINA -MAC285119XG EuroPipe
