DOUBLE BRANCH 45° - (836.075.075 S)
Part Of the Series: Double branch-45-180
Type no.: 836.075.075 S
EAN no.: 5705499402179
VVS no.: 160235375
RSK no.: 1549394
NRF no.: 2172608
LVI no.: 0253656
DOUBLE BRANCH 45°
-Pipe diameter: Ø75mm. Branch diameter: Ø75mm
-Stainless steel: AISI316L/EN1.4404
Product Specification | |
---|---|
Angle (°) | 45 |
Length (mm) | 183 |
Material | AISI 316L |
Material (EN) | EN 1.4404 |
Outlet Diameter (mm) | 75 |
Weight (kg) | 1,15 |
-
Downloads
-
Approval Information
For approval information, please refer to the below approval certificates.
US - IAPMO File No.3247-EuroPipe HACCP Food Safety Programme - Europe DK - VA 2.12/19349 EuroPipe DS432 AUS - WMKT00204 - 24 FR - DTA 14.1/12-1811_V3 EuroPipe HACCP Food Safety Programme - Australasia KR - Type Approval CPH42135-PE001 ABS - 23-2329630-PDA UR - 1055745 Product approval, EuroPipe and Drains PL - Hygienic Certificate - All Products DNV - TAP0000023-rev5, Sanitary discharge pipes Achilles Certificate - 46702-22 Bureau Veritas, 02375-I0 Pipes & Fittings MARINE - R4547 NATO CODIFICATION SYSTEM Lloyds Register LR22419510TA RINA -MAC285119XG EuroPipe
