LINEA CHANNEL 150x1000 - (670.100.015.55 S)
×
![]()
Part Of the Series: Channel-No membrane
Type no.: 670.100.015.55 S
EAN no.: 5705499001488
Size: 150x1000
LINEA CHANNEL 150x1000
-With screw lock
-No membrane
-Stainless steel: AISI316L/EN1.4404
| Product Specification | |
|---|---|
| Material | AISI 316L |
| Material (EN) | EN 1.4404 |
| Membrane Type | No Membrane |
| Minimum Height (mm) | 72 |
| Outlet Box | No |
| Shape | Rectangular |
| Size (mm) | 150x1000 |
| Weight (kg) | 4,45 |
-
Downloads
-
Approval Information
For approval information, please refer to the below approval certificates.
