SHOWER CHANNEL WATERLINE 700, SET - (378.070.056.4B)
Part Of the Series: Shower channel-Liquid membrane
Type no.: 378.070.056.4B
EAN no.: 5705499138184
NRF no.: 3394675
LVI no.: 3304478
Size: 50x700
SHOWER CHANNEL WATERLINE 700, SET
-With COPENHAGEN grating
-Floor: concrete and tiled
-Frame: rectangular
-Outlet: Ø75mm horizontal, inclusive water trap
-Stainless steel: AISI304/EN1.4301
Product Specification | |
---|---|
Floor | Concrete / Tiled |
Load Class EN1253 | K3 |
Material | AISI 304 |
Material (EN) | EN 1.4301 |
Membrane Type | Liquid Membrane |
Outlet Box | No |
Outlet Diameter (mm) | 75 |
Outlet Direction | Horizontal |
Outlet Placement | End |
Shape | Rectangular |
Size (mm) | 50x700 |
Weight (kg) | 3,18 |
-
Downloads
-
Approval Information
For approval information, please refer to the below approval certificates.
