UPPER PART SQUARE - (110.300.000)
Part Of the Series: Upper part-No membrane-145
Type no.: 110.300.000
EAN no.: 5705499106916
VVS no.: 153327710
Size: 145x145
UPPER PART SQUARE
-No supporting ring
-Floor: concrete and tiled
-Frame: 145x145mm
-Stainless steel: AISI304/EN1.4301
Product Specification | |
---|---|
Floor | Concrete / Tiled |
Load Class EN1253 | K3 |
Load Class EN1253 (kg) | K3 |
Material | AISI 304 |
Material (EN) | EN 1.4301 |
Number of Screw Holes | 2 |
Outlet Diameter (mm) | 110 |
Shape | Square |
Size (mm) | 145x145 |
Weight (kg) | 0,53 |
-
Downloads
-
Approval Information
For approval information, please refer to the below approval certificates.
