HYGIENICPRO END PIECE FOR GRATING - (670.000.030 S)
Part Of the Series: Grating-Channel-150
Type no.: 670.000.030 S
EAN no.: 5705499138566
HYGIENICPRO END PIECE FOR GRATING
-Semicircle
-Grating: 145x73mm
-Stainless steel: AISI316L/EN1.4404
Product Specification | |
---|---|
Load Class EN1253 | R50 |
Load Class EN1253 (kg) | R50 (5000) |
Material | AISI 316L |
Material (EN) | EN 1.4404 |
Minimum Height (mm) | 24 |
Number of Screws | 0 |
Shape | Semicircular |
Weight (kg) | 0,57 |
-
Downloads
-
Approval Information
For approval information, please refer to the below approval certificates.
