HYGIENICPRO CHANNEL 150x4000 CENTER OUTLET - (676CC040-20EF S)
Part Of the Series: Channel-No membrane
Type no.: 676CC040-20EF S
EAN no.: 5705499136982
LVI no.: 3305680
Size: 150x4000
HYGIENICPRO CHANNEL 150x4000 CENTER OUTLET
-High model. With outlet box
-Floor: concrete, tiled and resin
-No membrane
-Outlet: Ø110mm, vertical
-Stainless steel: AISI316L/EN1.4404
Product Specification | |
---|---|
Floor | Concrete / Tiled / Resin |
Material | AISI 316L |
Material (EN) | EN 1.4404 |
Membrane Type | No Membrane |
Minimum Height (mm) | 545 |
Outlet Box | Yes |
Outlet Diameter (mm) | 110 |
Outlet Direction | Vertical |
Outlet Placement | Center |
Shape | Rectangular |
Size (mm) | 150x4000 |
Weight (kg) | 33,96 |
-
Downloads
-
Approval Information
For approval information, please refer to the below approval certificates.
