SHOWER CHANNEL WATERLINE 1000 - (398.100.056.20)
Part Of the Series: Shower channel-Sheet membrane
Type no.: 398.100.056.20
EAN no.: 5705499138412
VVS no.: 155063010
RSK no.: 7121707
NRF no.: 3394729
Size: 50x1000
SHOWER CHANNEL WATERLINE 1000
-Floor: concrete and tiled
-Frame: rectangular
-Outlet: Ø50mm, vertical
-Stainless steel: AISI304/EN1.4301
Product Specification | |
---|---|
Floor | Concrete / Tiled |
Material | AISI 304 |
Material (EN) | EN 1.4301 |
Membrane Type | Sheet Membrane |
Outlet Box | No |
Outlet Diameter (mm) | 50 |
Outlet Direction | Vertical |
Outlet Placement | End |
Shape | Rectangular |
Size (mm) | 50x1000 |
Weight (kg) | 4,68 |
-
Downloads
-
Approval Information
For approval information, please refer to the below approval certificates.
