SHOWER CHANNEL WATERLINE 900 - (275.090.056.20)
×
![]()
Part Of the Series: Shower channel-Vinyl
Type no.: 275.090.056.20
EAN no.: 5705499122541
VVS no.: 155060009
RSK no.: 7121681
NRF no.: 3394733
LVI no.: 3304476
Size: 50x900
SHOWER CHANNEL WATERLINE 900
-Floor: vinyl
-Frame: rectangular
-Outlet: Ø50mm, vertical
-Stainless steel: AISI304/EN1.4301
| Product Specification | |
|---|---|
| Floor | Vinyl |
| Material | AISI 304 |
| Material (EN) | EN 1.4301 |
| Minimum Height (mm) | 128 |
| Outlet Box | No |
| Outlet Diameter (mm) | 50 |
| Outlet Direction | Vertical |
| Outlet Placement | End |
| Shape | Rectangular |
| Size (mm) | 50x900 |
| Weight (kg) | 2,90 |
-
Downloads
-
Approval Information
For approval information, please refer to the below approval certificates.
DK - MK 7.21/1664-21
DK - VA 2.44/19205-21
HACCP Food Safety Programme - Australasia
SE - RI.SE 0084-07 2021 Type 275, 398 DNV - TAP0000023-rev5, Sanitary discharge pipes PL - Hygienic Certificate - All Products ABS - 23-2329630-PDA Lloyds Register LR22419510TA_02 RINA -MAC320524XG EuroPipe FI-Tyyppihyväksyntä VTT-RTH-03128-08 Blücher Waterline 275,378-2017
