CHANNEL 200x6000 CENTER OUTLET - (674DH060-30BA)
Part Of the Series: Channel-Liquid membrane
Type no.: 674DH060-30BA
EAN no.: 5705499131079
Size: 200x6000
CHANNEL 200x6000 CENTER OUTLET
-Floor: concrete, tiled and resin
-Liquid membrane
-Outlet: Ø110mm, vertical
-Stainless steel: AISI304/EN1.4301
Product Specification | |
---|---|
Floor | Concrete / Tiled / Resin |
Material | AISI 304 |
Material (EN) | EN 1.4301 |
Membrane Type | Liquid Membrane |
Minimum Height (mm) | 152 |
Outlet Box | No |
Outlet Diameter (mm) | 110 |
Outlet Direction | Vertical |
Outlet Placement | Center |
Shape | Rectangular |
Size (mm) | 200x6000 |
Weight (kg) | 56,85 |
-
Downloads
-
Approval Information
For approval information, please refer to the below approval certificates.
